Professional Multi-Frequency Wireless Bug Detector
A RF DETECTOR WITH SIX DIFFERENT IDENTIFICATION PROTOCOLS
The Professional RF bug detector is an excellent device for finding and pinpointing modern wireless bugging devices. It activates in seconds and lets even the most novice of users, sweep and identify a nefarious signal. This unit feeds out a visual display of 6 distinctive types of signals simultaneously so you can find the exact type of signal you're searching for.
CDMA, GSM, GSM (DCS), WCDMA, Bluetooth WiFi, and Wi-Max are uniquely displayed for confirmation that the signal that you've found is indeed the corresponding signal to the type of bug. That might seem technical but the easiest way of explaining it, is that, when a specific signal is detected only the single frequency range spikes the graph.
An example of this is searching for a GPS tracking device. Other detectors would light up when ever any detectable signal is crossed. This could mean anything, and could even mean what you've found is a bundle of wires that is acting like a antenna extension. (An antenna extension is a wire that gives off a natural frequency unrelated to GPS tracker.) This is time lost searching in the wrong location, and can potentially create stress and anxiety that something is there when it's not. The Pro Wireless Detector eliminates that completely and instead would only spike the specific graph saving you time, energy, and effort.
This detector is a more advanced version of the Professional digital RF detector. The six bar graph signals display 10 unique protocols for a more precise understanding of the signal found. Sweep for hidden microphones, hidden wireless cameras, GSM baby monitors, GSM/GPRS/EDGE/3G video cameras, spy phones, GPS trackers, GSM/3G trackers, Bluetooth bugging devices, remotely activated recorders, GSM transmission devices, transmitting transmitters, Wi-Max high protocol transmitters, phone tapping, cell based devices, WiFi and Bluetooth enabled eavesdropping devices as well as many many others.
Another unique feature for this device is a listen mode to individually demodulate, the ability to detect GSM-1800, which is also hard to detect because of its low sensitivity at higher frequency ranges, and a extra data feed out to help isolate a specific signal in an environment.
IDENTIFY A SPECIFIC SIGNAL MADE EASY
The simplicity of the Professional Multi-Frequency protocol detector is that you don't have to be an expert to utilize the most advanced features. This unit is designed to be able to find a potential threats and identify what the device could be in seconds. Before you begin a sweep of the area a few things need to be considered.
Since there are many different types of bugging equipment it's important to know that these devices come in all sorts of shapes and sizes. Some devices are triggered upon sound, movement, and even the ability to remotely activate when desired. So consider the situation you're dealing with, an example would be if it's an office issue. The best time to perform a search would be during operation hours, or maybe staging a fake meeting in order to trick the criminal into remotely activating the device. Simulate everything that would normally be on. Turn on the lights, and any equipment that would normally be used in the area. If you have a CD player or radio, turn that on as well. The device needs to be transmitting in order to find it, so think about your situations, close the blinds, doors and preform multiple sweeps if needed.
Now once a sweep is about to begin take a step out of the room with the Professional Multi-signal wireless detector and adjust the vibration threshold. You do this by pressing down the joystick and turning on the device, moving the arrow up and down to vibrate only when a strong signal is detected. This will give a physical feedback the instant the bar graph reaches a high threshold and it is perfect for probing an area out of the line of sight.
Enter the environment and pay close attention to the graphs. Small spikes under four bars are phantom signals in the area, if a graph goes over five bars move the Pro Multi signal finder around in order to see if the levels increase or decrease. For a more direct isolation, activate the ATT+, the corresponding graph LED light will increase the strength for a particular signal type. If the signal found is irreverent to the search you can default the Professional Multi-Frequency wireless detector by pushing the joystick in the opposite direction to continue your sweep under normal mode.
When the Listening Mode is activated, more data can be acquired about the specific source by hearing the demodulation signal. This mode can be activated and distinguish between the types of transmissions. By pressing the joystick in this mode will temporarily be activated in order to distinguish the source.
It's important to probe every object in the area. eavesdropping devices come in all sorts of shapes and sizes. The Multi-Frequency RF detector is a short range device, intentionally designed for finding a specific source and prevent interference. Distance of each specific signal ranges so it is recommended that the Multi-Frequency detector be within 1-30ft. of an object probed.
Regardless of the results a physical search is always recommended. It's imperative that if a signal is found that a visual inspection take place. If you do come across a bugging device, continue to search. There's a high possibility that what you found is a "foolish bug" meant to distract you from more well hidden bugging equipment. Preform multi sweeps in the environment at different times once the first sweep is completed. Some devices are remotely activated and could slip under the radar of the first search. Take your time and if a strange device is identified keep going to eliminate any other potential threats.
WHY CHOOSE THIS PRO BUG DETECTOR?
Do you need to sweep an area with lots of radio interference? Is there naturally WiFi connected devices in the area? Do you need a premium detector that can isolate a specific type of signal? Then the Multi-Frequency RF detector is the upgrade to the Professional digital RF.
The professional multi signal wireless detector is designed specifically for finding modern bugging equipment within the range of 40MHz-6GHz. With six individual bar graphs that light up according to the specific signal found. The ability to detect the different levels simultaneously is an excellent advantage over other professional models, leading to a more accurate scan.
This detector is perfect for homes, offices, vehicles, and any other situation where potential cross signals can accrue. The ability to isolate a signal note by adjusting the thresh hold lets you focus in on only that signal even when other wireless connected devices are present. So while another device may register a WiFi printer alone, with the Multi Frequency detector you can register the hidden GSM cell based bug hidden inside.
- Detecting Audio Transmitters and Receivers
- Detecting GPS Tracker Frequencies
- Detecting Wireless Frequencies
- Detecting Illegal Wireless Tapping Devices
- Detecting Wireless Bugs
- Detecting Wireless Hidden Cameras
- Portable device for the inspection and location of wireless sources
- 6 channels of detection for different kinds of protocols
- Detection of GSM/CDMA/3G/4G
- Detection of Bluetooth/Wi-Fi/Wi-Max
- Can be used for tracing both regular sources and illegal eavesdropping devices
- 6 bar graphs with 10-segments each, for accurate location of RF sources
- 4 modes: Silent, vibration, visual and listen
- 2 levels of sensitivity (attenuator)
- Extra display shows which signal type has been detected
- Durable metallic body
- Microprocessor controlled
- Setup mode with selection the threshold level for vibration
DETECT THE FOLLOWING KINDS OF BUGGING DEVICES
- GSM baby-monitors/GSM alarm/GSM bugs
- GSM/GPRS/EDGE/3G video cameras
- GSM Spy phones
- GPS Trackers
- Bluetooth bugging devices
- Spy phones with Bluetooth/Wi-Fi
- Wi-Fi/Wi-Max bugging devices
- Wireless video cameras 2.4 Ghz
- Detection range is 30 feet
- Professional Wireless Bug Detector
- 2 Antennas
- 2 Batteries size AAA
- Cleaning Cloth
- Screw driver
- 90 Day Manufacturers Warranty
- Detection range is 30 feet
- Antenna 2 Omni-directional antennas
- Box Size 7 x 5 x 1.50
- Detection distance 1-10 meters
- Operation time 10-15 hours
- Power 2 AAA
- Unit Size 2.75 x 4.75 x .50
- Weight 1.00 LB
- Frequency Range (Up-Link Bands)
- CDMA, LT800 (4G) 824-849 MHz
- GSM 880-920 MHz
- GSM (DCS) 1710-1790 MHz
- WCDMA, 3G, GSM (PCS), DECT 1920-2000 MHz
- Bluetooth, Wi-Fi 2400-2480 MHz
- Wi-Max/Wi-Fi High/LTE (4G) 2500-7000 MHz
- Max Range 8 MHz - 7 GHz
Q: Can this unit distinguish what signal it is picking up?
A: Yes, it has 6 different frequency break downs on the unit.
Q: How far can this unit pick up signals?
A: The detection range is 30 feet.
Q: Why is there two antennas?
A: Each antenna is specifically calibrated to test within a certain max range and for a specific signal type.
Q: If I stand in the middle of my living room will I accurately pickup on everything in the room?
A: This item can pick up signals up to 30ft, but it is considered a short range device and we would recommend the closer you can get to the objects you are curious about the better. This can also help if the signal you are looking for is very weak.
Q: If I am wanting to locate audio, wireless video or a GPS tracker of some sort can this device do that?
Q: Do I need to purchase anything extra to use this RF detector?
A: No, this device will come with everything needed.
